Filling machines are mainly a small class of products in packaging machinery. From the perspective of packaging materials, they can be divided into liquid filling machines, paste filling machines, powder filling machines, and granular filling machines; It is divided into semi-automatic filling machines and automatic filling production lines.
The use and maintenance details of the automatic filling machine are as follows.
I. Adjustment of filling accuracy of automatic filling machine
1. The filling error is mainly determined by the filling volume, filling speed, and the opening and closing speed of the upper and lower valves. The switching speed of the upper and lower valves is related to the viscosity of the product. The higher the viscosity, the slower the switching speed of valve i.
2. Adjust the spring pressure of the valve door to be determined through trial filling measurement and the experience of the operator.
3. The switching speed of the thickened valve mainly adjusts the spring pressure of the valve. As the spring pressure increases, the valve opens and closes faster.
Second, the automatic filling machine safe use The automatic filling machine is a double-head liquid filling machine, the working object is liquid, and can not be used for other purposes. To ensure production safety, note the following:
1. This machine has no power setting and the normal air source is 4-6kg.
2. Do not wash the machine directly with water when disassembling and washing the machine.
3. If the injection nozzle overflows, press the safety emergency stop switch to ensure that the workshop is tidy.
4. The circuit of this machine is simple and should not be arbitrarily plugged.
5. When the cylinder ejection cannot be returned due to improper operation, please press this button to reset it.
Third, automatic filling machine equipment maintenance
1. The body of the automatic filling machine is made of stainless steel. Do not scratch the surface with sharp or hard sharp tools.
2. When removing and cleaning the piston, remove the fixing screws at the same time, so as not to affect the process requirements of the other one when removing the first one.
3. Before cleaning the piston-type filling machine, the remaining products in it should be cleaned, and then the bucket should be filled with gentle cleaning liquid. Our company recommends using warm water. If necessary, use soapy water, alcohol, or other cleaning solutions.
4. The cylinder is lubricated at the factory, please do not open or add any lubricating oil.
