Jerry Can F-style Gallon Bottle Capping Machine

Jerry Can F-style Gallon Bottle Capping Machine

Designed for F-style bottles,this automatic capping machine is with function of feeding bottle caps,and the working height can be adjusted according to bottles.It is widely used in chemical industries.

Product Detail

Product Tags

Jerry Can F-style Gallon Bottle Capping Machine-ZONESUN TECHNOLOGY LIMITED

Description:

Designed for F-style bottles,this automatic capping machine is with function of feeding bottle caps,and the working height can be adjusted according to bottles.It is widely used in chemical industries.

Jerry Can F-style Gallon Bottle Capping Machine-ZONESUN TECHNOLOGY LIMITED

Parameter:

Machine modelZS-XG441F
Bottle height≤300mm(Can be customized)
Bottle caps diameter15-60mm(Can be customized)
Working speed20-35 bottles/min (depending on bottle and caps)
Working voltageAC220V/110V 50-60HZ
Working powerAbout 1KW+0.4KW
Capping torqueMax 30Nm(Adjustable)
Cap feeder capacityAbout 2000-10000piece
Machine sizeAbout 2300*875*1985mm

Jerry Can F-style Gallon Bottle Capping Machine-ZONESUN TECHNOLOGY LIMITEDJerry Can F-style Gallon Bottle Capping Machine-ZONESUN TECHNOLOGY LIMITEDJerry Can F-style Gallon Bottle Capping Machine-ZONESUN TECHNOLOGY LIMITED
